Drawing
Parameter
| Boundary dimensions |
| d | 670 |
| D | 900 |
| B | 103 |
| r Min | 6 |
| Rated load (N) |
| Cr | 675000 |
| Cor | 1460000 |
| Rated load {kgf} |
| Cr | 68500 |
| Cor | 149000 |
| Speed ratings(rpm) |
| Grease | 480 |
| Oil | 560 |
| Fitting dimensions (mm) |
| d a (1) (Min) | 696 |
| Da(1) (Max) | 874 |
| r a (Max) | 5 |
Details
Chenxin International Industry Co., Ltdspecializes in selling NSK-69/670-Deep Groove Ball Bearing，Relevant information of NSK-69/670-Deep Groove Ball Bearing includes： Designation: 69/670 d:670 D:900 B:103 Brand:NSK Type:Deep Groove Ball Bearing ，Want to know more about NSK-69/670-Deep Groove Ball Bearing You can consult online or call the hotline, we will provide you with detailed service.
NSK-69/670-Deep Groove Ball Bearing is widely used.NSK-69/670-Deep Groove Ball Bearing is mainly used in construction machinery, machine tools, automobiles, metallurgy, mines, petroleum, machinery, electric power, railways and other industries. The price of NSK-69/670-Deep Groove Ball Bearing sold by the company is reasonable, the quality is guaranteed, the service in all aspects is provided, and the customer's demand is satisfied.
