Drawing
Parameter
| Boundary dimensions |
| d | 35 |
| D | 80 |
| B | 21 |
| r Min | 1.5 |
| r 1 (Min) | 1 |
| Rated load (N) |
| Cr | 36500 |
| Cor | 24200 |
| Rated load {kgf} |
| Cr | 3750 |
| Cor | 2460 |
| Speed ratings(1)(rpm) |
| Grease | 7100 |
| Oil | 9500 |
| Fitting dimensions (mm) |
| d a (Min) | 44 |
| Da (Max) | 71 |
| r a (Max) | 1.5 |
| Bearing No.(2) |
| Single row | 7307B |
| DB | 7307DB |
| DF | 7307DF |
| DT | 7307DT |
| Rated load(Duplex type) (N) |
| Cr | 59500 |
| Cor | 48500 |
| Rated load(Duplex type) {kgf} |
| Cr | 6100 |
| Cor | 4950 |
| Duplex type Speed ratings rpm(1) (rpm) |
| Grease | 5600 |
| Oil | 7500 |
| Duplex type Function Point distance(mm) a0(mm) |
| back-to-back | 69.2 |
| Face-to-face | 27.2 |
| Duplex type Fitting dimensions mm |
| d b (3) (Min) | 41 |
| Db (Max) | 74 |
| r b (3) (Max) | 1 |
Details
Chenxin International Industry Co., Ltdspecializes in selling NSK-7307B-Angular Contact Ball Bearing，Relevant information of NSK-7307B-Angular Contact Ball Bearing includes： Designation: 7307B d:35 D:80 B:21 Brand:NSK Type:Angular Contact Ball Bearing ，Want to know more about NSK-7307B-Angular Contact Ball Bearing You can consult online or call the hotline, we will provide you with detailed service.
NSK-7307B-Angular Contact Ball Bearing is widely used.NSK-7307B-Angular Contact Ball Bearing is mainly used in construction machinery, machine tools, automobiles, metallurgy, mines, petroleum, machinery, electric power, railways and other industries. The price of NSK-7307B-Angular Contact Ball Bearing sold by the company is reasonable, the quality is guaranteed, the service in all aspects is provided, and the customer's demand is satisfied.
